M-Line Suspended Lighting Systems

need assistance on this product?

call us now on 01582 369005

Description

Suspended lighting is popular throughout all industries where lighting has practical or aesthetic purposes. Whether it’s for maintaining CIBSE levels or blowing away clients the moment they walk through the door, suspended linear lighting is a dynamic way to introduce height and levels into a room while utilising direct and indirect lighting elements within the same linear fitting, for the perfect task and ambient light.

For simple, clean runs of light that fully illuminate office and commercial spaces to ensure good illumination, our M-Line suspended lighting systems are available in standard lengths up to 2824mm. Custom lengths for continuous lighting systems are available to order and bespoke geometric-shaped feature lights with fully illuminated corners can be created upon the client’s request.

Surface mounting is achieved by directly fixing through the rear of the profile. The suspension is made simple using a single-point ceiling bracket with 2m adjustable stainless steel wire system. For additional spreads of light or to create bold focal points, uplighting is available on lengths from 584mm upwards.

No matter the application, the suspended M-Line system will provide high-lumen output and bright illumination wherever it is used. This clean, refined luminaire option will ensure that any application stands out while maintaining a well-constructed, impressive visual as standard.

  • Aluminium extruded sections in 9 standard lengths
  • Bespoke lengths available in 140mm increments
  • 104 lumens per watt
  • Colour options in 3000K/4000K/5000K
  • Custom shapes available subject to design
  • Incorporates European branded LED drivers
  • Direct/Indirect lighting options available for suspended fittings
  • Utilises latest generation long-life LEDs from leading manufacturers
  • Clip-in gear tray for easy installation
  • Screwless end caps available on request
  • Opal polycarbonate diffuser
  • Tuneable white and RGB options available
  • Dimmable and emergency options available
  • Compatible with Casambi wireless control system
  • Dual circuit option available
  • CRI>80 as standard, CRI 90 on request
  • L70B50 lifetime 102,000 hours
  • 5-year warranty

Technical & Design Info

Suspended Direct Lighting System
Product Code LED Wattage Lumen Output Lumen/watt Colour Temp. Size
MLE584 13W 1298 104 4000K 584 × 50mm
MLE864 19W 1947 104 4000K 864 × 50mm
MLE1144 25W 2596 104 4000K 1144 × 50mm
MLE1424 31W 3245 104 4000K 1424 × 50mm
MLE1704 38W 3895 104 4000K 1704 × 50mm
MLE1984 44W 4543 104 4000K 1984 × 50mm
MLE2264 50W 5192 104 4000K 2264 × 50mm
MLE2544 56W 5841 104 4000K 2544 × 50mm
MLE2824 63W 6490 104 4000K 2824 × 50mm
NOTE: Includes 2m suspension kits (longer bespoke lengths available in 140mm increments)
Suspended Direct/Indirect Lighting System/70% Direct/30% Indirect
Product Code LED Wattage Lumen Output Lumen/watt Colour Temp. Size
MLD584 17W 1788 104 4000K 584 × 50mm
MLD864 26W 2683 104 4000K 864 × 50mm
MLD1144 34W 3570 104 4000K 1144 × 50mm
MLD1424 44W 4543 104 4000K 1424 × 50mm
MLD1704 53W 5518 104 4000K 1704 × 50mm
MLD1984 62W 6490 104 4000K 1984 × 50mm
MLD2264 72W 7464 104 4000K 2264 × 50mm
MLD2544 81W 8437 104 4000K 2544 × 50mm
MLD2824 91W 9411 104 4000K 2824 × 50mm
NOTE: Includes 2m suspension kits (longer bespoke lengths available in 140mm increments)

Section Option Code Description
1 – EMERGENCY Leave blank if no emergency
/M Emergency
/MZ DALI Emergency
2 – CONTROL /ND Non Dim
/DA DALI Dim
/BTC Casambi Dim
/2DA Dual Channel DALI Dim
/2BTC Dual Channel Casambi Dim
3 – FINISH /9016 RAL9016 White
/9005 RAL9005 Black
/RA Any RAL Colour
/ See datasheet for new finish options
4 – CCT /4K 4000K
/3K 3000K (light output -6%)
/5K 5000K
5 – CRI /80 CRI>80 (typical 84)
/90 CRI>90
